Specifications | Measurement |
Product Part Number | 66313x |
Wheel Size (in) | 17.5x6.00 |
Mounting System | Ball Seat |
Bolt Holes | 6 |
Bolt Circle | 222mm |
Bolt Hole Diameter | 32mm |
Hub Bore | 164mm |
Approx. Weight (kgs) | 11.3 kgs |
Outset (mm) | 135.763 mm |
Inset (mm) | 117.7544 mm |
Max Load (kgs) | 1750 kgs |
Max Cold Infl. (psi) | 112 psi |
Valve Stem | TR553C |
Part Number | Finish |
663133 | Mirror Polished |
†See our Warranty page for more information
Availability of the product may vary; please check with our team.
