88067x
22.5" x 8.25" - Hub Pilot - 285.75mm Bolt Circle
Featuring Alcoa® Wheels’ proprietary MagnaForce® alloy, vHub™ Bore Technology, it is a lightweight champion. The latest in advanced innovation, manufacturing and engineering on the road. Ideal for heavy-duty truck, trailer, and motorhome applications.
| Specifications | Measurement |
| Product Part Number | 88067x |
| Wheel Size (in) | 22.5" x 8.25" |
| Mounting System | Hub Pilot |
| Bolt Holes | 10 |
| Bolt Circle | 285.75mm |
| Bolt Hole Diameter | 26mm |
| Hub Bore | 220.1mm |
| Approx. Weight (kgs) | 39 kgs |
| Outset (mm) | 6.6 mm |
| Inset (mm) | 5.81 mm |
| Max Load (kgs) | 7400 kgs |
| Max Cold Infl. (psi) | 130 psi |
| Valve Stem | TV554D |
| Part Number | Finish |
| 880671 | Mirror Polish Outside Only |
| 880672 | Mirror Polish Inside Only |
| 880673 | Mirror Polish Both Sides |
| 880677 | High Polish |
| 88067BLK | Dura-Black™ |
| 880670DB | Brushed with Dura-Bright |
| 880671DB | Mirror Polish Outside Only with Dura-Bright |
| 880672DB | Mirror Polish Inside Only with Dura-Bright |
| 880673DB | Mirror Polish Both Sides with Dura-Bright |
| Accessories and Mounting Hardware | Part Number |
| Front Hub Cover (Includes Nut Covers Where Applicable) |
079100DT, 079300DT, 079500DT, 079200DT, 079400DT, 079600DT |
| Rear Hub Cover (Includes Nut Covers Where Applicable) |
- |
| Nut Cover Only (Not Intended to Secure Hub Covers) |
N/A |
| Alcoa® Mounting Hardware Kits | - |
Related Documents
†See our Warranty page for more information
Availability of the product may vary; please check with our team.
