77349x

19.5" x 7.5RW" - Hub Pilot - 275mm Bolt Circle
Specifications Measurement
Product Part Number 77349x
Wheel Size (in) 19.5" x 7.5RW"
Mounting System Hub Pilot
Bolt Holes 8
Bolt Circle 275mm
Bolt Hole Diameter 24mm
Hub Bore 221.1mm
Approx. Weight (kgs) 17 kgs
Outset (mm) 154.94 mm
Inset (mm) 133.858 mm
Max Load (kgs) 2998 kgs
Max Cold Infl. (psi) 130 psi
Valve Stem TR553C
Part Number Finish
773491 Mirror Polish Outside Only
773497 LvL ONE

See our Warranty page for more information

Availability of the product may vary; please check with our team.
