Specifications | Measurement |
Product Part Number | 76329x |
Wheel Size (in) | 19.5" x 6" |
Mounting System | Hub Pilot |
Bolt Holes | 10 |
Bolt Circle | 225mm |
Bolt Hole Diameter | 15mm |
Hub Bore | 170.2mm |
Approx. Weight (kgs) | 12 kgs |
Outset (mm) | 135.89 mm |
Inset (mm) | 122.428 mm |
Max Load (kgs) | 1814 kgs |
Max Cold Infl. (psi) | 130 psi |
Valve Stem | TR553C |
Part Number | Finish |
763291 | Mirror Polish Outside Only |
763291DB | Mirror Polish Outside Only with Dura-Bright |
763292 | Mirror Polish Inside Only |
763292DB | Mirror Polish Inside Only with Dura-Bright |
763297 | LvL ONE |
†See our Warranty page for more information
Availability of the product may vary; please check with our team.
