22.5" x 7.5" - Hub Pilot - 275mm Bolt Circle
Specifications Measurement
Product Part Number 87340x
Wheel Size (in) 22.5" x 7.5"
Mounting System Hub Pilot
Bolt Holes 10
Bolt Circle 275mm
Bolt Hole Diameter 26mm
Hub Bore 221.1mm
Approx. Weight (kgs) 24 kgs
Outset (mm) 159.512 mm
Inset (mm) 138.176 mm
Max Load (kgs) 3311 kgs
Max Cold Infl. (psi) 130 psi
Valve Stem TR555D
Part Number Finish
873407 LvL ONE

See our Warranty page for more information

Availability of the product may vary; please check with our team.
