16028x
16" x 6K" - Hub Pilot - 6.5" Bolt Circle
| Specifications | Measurement |
| Product Part Number | 16028x |
| Wheel Size (in) | 16" x 6K" |
| Mounting System | Hub Pilot |
| Bolt Holes | 8 |
| Bolt Circle | 6.5" |
| Bolt Hole Diameter | 0.67" |
| Hub Bore | 4.88" |
| Approx. Weight (kgs) | 9 kgs |
| Outset (mm) | 137.16 mm |
| Inset (mm) | 122.936 mm |
| Max Load (kgs) | 1261 kgs |
| Max Cold Infl. (psi) | 95 psi |
| Valve Stem | TR553 |
| Part Number | Finish |
| 160281 | Mirror Polish Outside Only |
| 160281DB | Mirror Polish Outside Only with Dura-Bright |
| 160282 | Mirror Polish Inside Only |
| 160282DB | Mirror Polish Inside Only with Dura-Bright |
