24.5" x 8.25" - Hub Pilot - 285.75mm Bolt Circle
Specifications Measurement
Product Part Number 98U69x
Wheel Size (in) 24.5" x 8.25"
Mounting System Hub Pilot
Bolt Holes 10
Bolt Circle 285.75mm
Bolt Hole Diameter 26mm
Hub Bore 220.1mm
Approx. Weight (kgs) 25 kgs
Outset (mm) 167.64 mm
Inset (mm) 145.542 mm
Max Load (kgs) 3311 kgs
Max Cold Infl. (psi) 130 psi
Valve Stem TR555D
Part Number Finish
98U691 Mirror Polish Outside Only
98U691DB Mirror Polish Outside Only with Dura-Bright
98U692 Mirror Polish Inside Only
98U692DB Mirror Polish Inside Only with Dura-Bright
98U697 LvL ONE

See our Warranty page for more information

Availability of the product may vary; please check with our team.
