Description
ALCOA WHEELS 818551 ON SALE | 22.5×11.75
Alcoa Wheels is the latest in advanced innovation, manufacturing, and engineering on the road. It features Alcoa’s proprietary MagnaForce® alloy and vHub™ Bore Technology and is ideal for heavy-duty truck, trailer, and bus applications.
| Specifications | Measurement |
| Product Part Number | 818551 |
| Wheel Size (in) | 22.5×11.75 |
| Mounting System | Hub Pilot |
| Bolt Holes | 10 |
| Bolt Circle | 335mm |
| Bolt Hole Diameter | 32|26mm |
| Hub Bore | 281mm |
| Approx. Weight (kgs) | 24.8|25.0 kgs |
| Outset (mm) | N/A mm |
| Inset (mm) | 119.9896 mm |
| Max Load (kgs) | 5000 kgs |
| Max Cold Infl. (psi) | 130 psi |
| Valve Stem | 54MS-00 |
Alcoa Wheels Key Features:
The Alcoa 818551 22.5 x 11.75-inch forged aluminum wheel for heavy-duty commercial vehicles. The wheel is for hub-piloted axles with a 335mm bolt circle and is rated for a maximum load of 5000kg (11,023 lbs).
The 818551 suits most European trucks in steer application. Not suitable for Scania
